Equipment Guide
Review exterior and interior dimensions, tare weight, maximum gross weight, and volume before planning your shipment.
Explore 11 common container types with exterior and interior dimensions, tare weight, maximum gross weight, and volume presented directly on this page.
Container Cards
Use the category controls to view dry, refrigerated, open-top, or flatrack container specifications.
Dry Container
Dry Container
Dry Container
Dry Container
Refrigerated
Refrigerated
Open Top
Open Top
Open Top
Flatrack
Flatrack
Comparison
Compare the complete metric and imperial specifications for every listed container type.
Metric and imperial values are displayed together for direct comparison.
| Container | Length | Width | Height | |||
|---|---|---|---|---|---|---|
| Exterior | Interior | Exterior | Interior | Exterior | Interior | |
| 20ft Dry Standard Container | 6.058 m19.88 ft | 5.898 m19.35 ft | 2.438 m8 ft | 2.352 m7.72 ft | 2.591 m8.5 ft | 2.385 m7.83 ft |
| 20ft Dry High Cube Container | 6.058 m19.88 ft | 5.898 m19.35 ft | 2.438 m8 ft | 2.350 m7.71 ft | 2.896 m9.50 ft | 2.695 m8.84 ft |
| 40ft Dry Standard Container | 12.192 m40 ft | 12.032 m39.48 ft | 2.438 m8 ft | 2.352 m7.72 ft | 2.591 m8.5 ft | 2.385 m7.83 ft |
| 40ft Dry High Cube Container | 12.192 m40 ft | 12.032 m39.48 ft | 2.438 m8 ft | 2.352 m7.72 ft | 2.896 m9.5 ft | 2.690 m8.83 ft |
| 20ft Refrigerated Container | 6.058 m19.88 ft | 5.500 m18.04 ft | 2.438 m8 ft | 2.298 m7.539 ft | 2.591 m8.5 ft | 2.276 m7.47 ft |
| 40ft High Cube Refrigerated Container | 12.192 m40 ft | 11.590 m38.02 ft | 2.438 m8 ft | 2.294 m7.53 ft | 2.896 m9.5 ft | 2.544 m8.35 ft |
| 20ft Standard Open Top Container | 6.058 m19.88 ft | 5.898 m19.35 ft | 2.438 m8 ft | 2.352 m7.72 ft | 2.591 m8.5 ft | 2.348 m7.7 ft |
| 40ft Standard Open Top Container | 12.192 m40 ft | 12.032 m39.48 ft | 2.438 m8 ft | 2.352 m7.72 ft | 2.591 m8.5 ft | 2.348 m7.7 ft |
| 40ft High Cube Open Top Container | 12.192 m40 ft | 12.032 m39.48 ft | 2.438 m8 ft | 2.352 m7.72 ft | 2.896 m9.5 ft | 2.653 m8.7 ft |
| 20ft Flatrack Container | 6.058 m19.88 ft | 5.553 m18.22 ft | 2.438 m8 ft | 2.194 m7.2 ft | 2.591m8.5 ft | 2.213 m7.26 ft |
| 40ft Flatrack Container | 12.192 m40 ft | 11.686 m38.34 ft | 2.438 m8 ft | 2.374 m7.79 ft | 2.591 m8.5 ft | 1.955 m6.41 ft |
Tare weight, maximum gross weight, and volume in both unit systems.
| Container | Tare Weight | Max Gross | Volume |
|---|---|---|---|
| 20ft Dry Standard Container | 2,330 kg5,137 lb | 24,000 kg52,911 lb | 33.1 m³1,169 ft³ |
| 20ft Dry High Cube Container | 2,360 kg5,203 lb | 30,480 kg67,197 lb | 37.30 m³1,317 ft³ |
| 40ft Dry Standard Container | 4,000 kg8,819 lb | 30,480 kg67,197 lb | 67.5 m³2,384 ft³ |
| 40ft Dry High Cube Container | 4,200 kg9,259 lb | 30,480 kg67,197 lb | 76.2 m³2,691 ft³ |
| 20ft Refrigerated Container | 2,980 kg6,570 lb | 30,480 kg67,197 lb | 28.8 m³1,017 ft³ |
| 40ft High Cube Refrigerated Container | 4,760 kg10,494 lb | 34,000 kg74,957 lb | 67.5 m³2,384 ft³ |
| 20ft Standard Open Top Container | 2,410 kg5,313 lb | 24,000 kg52,911 lb | 32.5 m³1,148 ft³ |
| 40ft Standard Open Top Container | 4,260 kg9,392 lb | 30,480 kg67,197 lb | 65.9 m³2,327 ft³ |
| 40ft High Cube Open Top Container | 4,300 kg9,480 lb | 30,480 kg67,197 lb | 75.1 m³2,652 ft³ |
| 20ft Flatrack Container | 2,800 kg6,173 lb | 34,000 kg74,957 lb | -- |
| 40ft Flatrack Container | 4,900 kg10,803 lb | 45,000 kg99,208 lb | -- |
